Details

Dichroic Mirror
Catalog: Visible range
Introduction:

Description

Dichroic Mirror is designed to selectively pass light of a small range while reflecting other colors in visible range.


* Angle of incidence of 45.0° or similar among customer request
* High wavelength accuracy +/-3nm at T50%
* Our thickness tolerance limits are ±0.1 mm
* Clear aperture of at least 95%

OBO offers high-quality additive and subtractive Dichroic Filters with a strong emphasis on durability. For less demanding specifications for general lighting we also supply customer requested colors.

* Please contact Orange Bright Optic for further information on Dichroic Mirror coating capabilities to discuss your current requirements, or to request a quote.
